(1) Lock terminal (12V/1A)
(1) Exit request input
Unlock using an NFC card or UniFi Identity mobile app
Connect and power using PoE+
IP55 weather resistance (-30 to 40°C)
Taxa Timbru Verde
este inclusa in pretul produsului
(1) Lock terminal (12V/1A)
(1) Exit request input
Unlock using an NFC card or UniFi Identity mobile app
Connect and power using PoE+
IP55 weather resistance (-30 to 40°C)
| Dimensions | 126 x 45 x 37.45 mm |
| Weight | 140 g |
| Enclosure material | Polycarbonate, aluminum alloy |
| Mounting | Wall mount, gang box mount |
| Weatherproofing | IP55 |
| Networking interface | 10/100 MbE RJ45 port |
| Connectivity | Ethernet BLE 4.2 |
| Digital input | (1) Exit request |
| Lock terminals | (1) 12V, 1A |
| Power method | PoE+ |
| Max. power consumption | 18W |
| ESD/EMP protection | Air: ±8kV, contact: ± 4kV |
| Button | (1) Factory reset |
| Tamper switch | Yes |
| Speaker | Buzzer |
| NFC frequency | 13.56 Mhz |
| NFC read range | < 50 mm |
| NFC standards | ISO 14443A, 14443B, 15693 |
