Dimensions
Device: 53 x 49 x 23.5 mm Mount: 41.3 x 36.6 x 3.1 mm
Weight
Device: 47.8 g With mount: 70 g
Enclosure Material Polycarbonate
Mount Material Galvanized steel
Mounting Adhesive, magnet and screw mount
Connectivity SuperLink (Proprietary)
Sensor Features
Temperature Sensor ✓
Other 3.5 mm AUX jack for water leak probe
Power Method Lithium battery CR123A
Battery Life Up to 6 years
Supported Voltage Range 3V
Max. Power Consumption 34.9mW
Antenna Gain SuperLink 0 dBi
Max. TX Power SuperLink 14 dBm
Operating Frequency
US 915.6–927.6 MHz
Max. Range SuperLink 2 km
LEDs (1) Status: R/B/W (1) Signal: B/R
Buttons (1) Factory-reset (1) Function button
Ambient Operating Temperature -20 to 40° C
Ambient Operating Humidity 10 to 90% noncondensing
Certifications FCC, IC, CE
Application Requirements
Web Application UniFi Protect
Mobile App UniFi Protect iOS™ and Android™
USL-Environmental
