AirFiber este o revolutionara solutie Punct la Punct in banda de 24GHz de la Ubiquiti Networks. Avand o forma compacta si cu un factor de eficienta sporit, se pot atinge performate de pana la 1.4+Gbps agregate, pe distante de pana la 13+km.
Designed to be a high-performance backhaul, the airFiber®24 delivers amazing wireless throughput of up to 1.4+ Gbps, surpassing conventional wired backhauls. The airFiber®24 operates in worldwide, license-free, 24 GHz frequencies. Users can deploy airFiber24 almost anywhere they choose (subject to local country regulations).
airFiber features a dual-independent, 2x2 MIMO, high-gain reflector antenna system. Separate yet integrated transmit ( TX) and receive (RX) antennas help extend link budgets by eliminating the extra RF losses caused by the switches or duplexers required in systems with common TX/RX antennas.
Conventional wireless standards impose a latency by having to receive a packet before a packet is transmitted. airFiber can transmit data synchronously without any wait time. airFiber features traditional TDD and FDD modes of operation in addition to the proprietary Hybrid Division Duplexing (HDD) mode, which provides a breakthrough in range and spectral efficiency performance.
Based on the ranging algorithm built into the air protocol, the airFiber radios use patent-pending HDD technology to calculate the propagation delay and know when each radio can transmit and receive, so they send packets in precise synchronization. Packet transmission latency is virtually eliminated.
For seamless monitoring and settings is used in the unit 2 Ethernet ports, one of whom is designed only for management 2nd one for data and management.
Connectors and Interfaces
|LAN speed:||(1) 10/100/1000Mbps + (1) 10/100Mbps (managment)|
|Other features:||RJ-12 - Alignment Tone Port|
|Wind load [km/h]:||200|
|Designed for mast diameter [mm]:||30 up to 100|
|Operating temperature [°C]:||-40 up to 55|
|Max. power consumption [W]:||50|
|Power over Ethernet:||42 .. 58V DC|
|Operating system:||airOS F|
|Default IP address:||192.168.1.20|
|Default login and password:||ubnt / ubnt|
|EIRP [dBm]:||33 (FCC/IC), 20 (CE)|
|Frequency range [MHz]:||24050 - 24250|
|Cross-Pol Isolation [dB]:||28|
|F/B ratio [dB]:||70|
|Channel bandwidth [MHz]:||100|
|Transmission speed - 24GHz [Mb/s]:||760|
|Beam angle - H. pol. [°]:||3,5|
|Beam angle - V. pol. [°]:||3,5|
|Antenna gain [dBi]:||Tx = 33, Rx = 38|
- Capacitate Wireless
- 1.40 Gbps
- Capacitate LAN
- 1 Gbps
- 24 GHz
- Castig Antena
- 38 dBi
